Stock Patterns
Mild steel and 304/316 stainless in most items. Standard stock size is 4' x 10'.
Exotic Alloys
Custom perforation in 321SS, 317LSS, Monel, Hastelloy C, Inconel, and 400 series stainless.
Fast Delivery
Items not in stock available in 3-10 days from our stocking warehouses.
Available Materials
We stock and custom perforate a wide range of materials:
We can also custom perforate alloys such as 321SS, 317LSS, Monel, Hastelloy C, Inconel, 400 series stainless, and more. Non-standard sizes and alloys are also available. We are also capable of decorative patterns.
Custom Patterns Available
Please contact our sales staff to help meet your specific requirements.
How to Order
Provide the following information when ordering perforated metal
Pattern Details
- Opening (hole size)
- Centers
- Open area
- Pattern type
Material Specs
- Desired alloy
- Thickness of material
Dimensions
- Overall dimensions
- Quantity required
- Margins (if required)
Stock Patterns
PSM Perforated Metal Stock List
HOLE SIZE | CENTERS | GAUGES | OPEN AREA % |
|---|---|---|---|
| 1/32″ | 1/16″ | 22 | 22% |
| .050″ | .066″ STR | 24 | 45% |
| 1/16″ | 3/32″ | 20,18 | 45% |
| 1/16″ | 7/64″ | 16 | 30% |
| 1/16″ | 1/8″ | 20-18 | 23% |
| 5/64″ | 1/8″ | 20-16 | 36% |
| 3/32″ | 5/32″ | 20-16 | 33% |
| .117″ | 5/32″ | 18-16 | 51% |
| 1/8″ | 3/16″ | 22-11 | 40% |
| 1/8″ | 7/32″ | 16,14 | 29% |
| 1/8″ | 7/32″ | 16,14 | 29% |
| 5/32″ | 3/16″ | 18-16 | 63% |
| 5/32″ | 1/4″ | 20-14 | 36% |
| 3/16″ | 7/32″ | 20-16 | 67% |
| 3/16″ | 1/4″ | 20-14 | 51% |
| 3/16″ | 5/16″ | 16-3/16″THK | 33% |
| 1/4″ | HEX | 20,22 | 79% |
| 1/4″ | 5/16″ | 20-14 | 58% |
| 1/4″ | 3/8″ | 18-1/4″THK | 40% |
| 1/4″ | 3/8″STR | 16-11 | 35% |
| 1/4″ | 1/2″STR | 16-11 | 23% |
| 5/16″ | 7/16″STR | 16-1/4″THK | 50% |
| 3/8″ | 9/16″ | 16-1/4″THK | 40% |
| 1/2″ | 11/16″ | 16-1/4″THK | 48% |
| 5/8″ | 7/8″ | 14,11 | 46% |
| 3/4″ | 1″ | 16-1/4″THK | 51% |
| 1″ | 1-3/8″ | 11-1/4″THK | 58% |
| 1″ | 1-3/8″ | 11-1/4″THK | 48% |
| 1-1/4″ | 1-5/8″ | 11-1/4″THK | 54% |
| 1-1/2″ | 2″ | 11-1/4″THK | 51% |
| 1-1/2″ | 2″ | 11-1/4″THK | 51% |
| 2″ | 2-1/2″ | 11-1/4″THK | 58% |
| 2-1/2″ | 3″ | 11-1/4″THK | 63% |
| 3″ | 3-1/2″ | 11-1/4″THK | 67% |
| 3-1/2″ | 4″ | 11-1/4″THK | 70% |
| 4″ | 4-1/2″ | 11-1/4″THK | 72% |
Ready to Get Started?
Contact us today for a quote on your perforated metal requirements.
Or call us at (866) 596-7537
